Computer-controlled lockstitch sleeve setting machine
Product Feature:
Product introduction
Computer-controlled lockstitch sleeve setting machine
2.The machine comes with the direct-drive system,in which a compact AC servo motor is directly joined to the main shaft.
3.It offers a quick startup,increased stopping accuracy and excellent responsiveness.
4.Computer-controlled lockstitch sleeve setting machine adopts horizontal-axis full-rotary non-lubricated hook.
5.The machine has special feed system,through intermittent belt feed with the direct-driven steeping motor,which can prevent an abrupt change in the shirring amount.
Product specifications
Computer-controlled lockstitch sleeve setting machine
Model | DT-2100 |
Max sewing speed*1 | 3500sti/min(feed pitch 1.5-4.0mm) |
Feed system | Intermittent belt feed with the direct-driven steeping motor |
Stitch length(both top and bottom) | 1.5-6.0mm |
Needle bar stroke | 30.7mm |
Needle | DP×17#10-#14 |
Thread take-up | Link type |
Hook | Horizontal-axis full-rotary non-lubricated hook |
Presser foot lift | By hand:5.5mm ,Auto:10mm |
Amount of the alternating vertical movement of the presser foooot the presser foot and walking foot | Max.3.5mm |
Adjustment of amount of the The alternating vertical movement of the presser foooot the presser foot and walking foot | Adjustment of stopping position in slot |
Bottom and variable top feed stitch adjusting method | Data entry through the operation panel,stepping motor |
Minimum resolution of bottom and variable top feed adjustment | 0.1mm |
Number of programs that can be input | 99 programs |
Number of steps that can be input(for one program) | 30steps |
Lubrication | No lubrication |
Needle thread tension | Active tension(electric thread tension control system) |
Right and left alternating sewing | Possible |
Automatic reverse feed function | Provided as standard |
Soft-start function | Provided as standard |
Auto-lifter | Provided as standard |
Power requirement/Power consumption | Single-phase 200-240V,560VA |
Product feature and application
Computer-controlled lockstitch sleeve setting machine
1.The machine has touch-sensitive type LCD,which makes operation easy and improve performance.
2.The machine head is dry,making maintenance easy and ensuring clothing clean.
3.Increased lift of the press foot is easy for removal of a finished portion.
4.Stitch length is increased to ensure an adequate shirring amount even when a heavy material is used.
